Straight Flails
Please use these navigation links to find the flail you have or require.
All measurements are in mm's.
Please click on the 'Part Number' inside the table to see a picture and profile of the selected part.
Please contact us for prices and further information about our products.
Please note, we do not supply genuine flails & parts unless indicated.
Any indicated OEM part numbers are used for reference only.
Dimensions and weights are approximate.
Straight Flails Round Hole
| Part Number | Width | Thickness | Hole Size | Length |
|---|---|---|---|---|
| FD-wex-01 | 20 | 2 | 8 | 135 |
|
||||
| FD-bcs-01 | 30 | 3 | 13 | 100 |
|
||||
| FD-tri-05 | 32 | 3 | 10.5 | 115 |
|
||||
| FD-rlg-03 | 32 | 3 | 10.5 | 135 |
|
||||
| FD-mur-22 | 35 | 5 | 14.5 | 114 |
|
||||
| FD-bre-50 | 40 | 5 | 12.5 | 78 |
|
||||
| FD-agc-02 | 40 | 5 | 16 | 113 |
|
||||
| FD-fei-55 | 40 | 6 | 12.5 | 130 |
|
||||
| FD-sic-11 | 40 | 6 | 16.5 | 136 |
|
||||
| FD-cel-29 | 40 | 8 | 16.5 | 115 |
|
||||
| FD-nob-17 | 40 | 8 | 16.5 | 132 |
|
||||
| FD-nob-34 | 40 | 8 | 16.5 | 235 |
|
||||
| FD-agm-08 | 40 | 8 | 20.5 | 111 |
|
||||
| FD-bem-05 | 40 | 15 | 16.5 | 115 |
|
||||
| FD-nob-38 | 45 | 8 | 16.5 | 125 |
|
||||
| FD-mas-58 | 45 | 8 | 16.5 | 135 |
|
||||
| FD-ind-189 | 50 | 6 | 20 | 245 |
|
||||
| FD-gre-01 | 50 | 6 | 25 | 132 |
|
||||
| FD-gre-02 | 50 | 6 | 25 | 162 |
|
||||
| FD-brt-14 | 50 | 8 | 25.5 | 113 |
|
||||
| FD-riv-52 | 50 | 8 | 25.5 | 200 |
|
||||
| FD-mal-21 | 50 | 10 | 16.5 | 200 |
|
||||
| FD-cel-26 | 50 | 10 | 17 | 120 |
|
||||
| FD-teh-102 | 50 | 10 | 20.5 | 134 |
|
||||
| FD-zap-09 | 50 | 10 | 20.5 | 185 |
|
||||
| FD-sek-03 | 60 | 7 | 25.5 | 205 |
|
||||
| FD-tie-01 | 60 | 7 | 25.5 | 212 |
|
||||
| FD-fei-09 | 60 | 8 | 25.5 | 250 |
|
||||
| FD-fei-12 | 60 | 8 | 25.5 | 230 |
|
||||
| FD-fei-52 | 60 | 8 | 25.5 | 150 |
|
||||
| FD-fei-33 | 60 | 8 | 25.5 | 150 |
|
||||
| FD-sic-04 | 60 | 8 | 25.5 | 195 |
|
||||
| FD-peg-36 | 60 | 8 | 25.5 | 205 |
|
||||
| FD-zzz-44 | 60 | 8 | 25.5 | 210 |
|
||||
| FD-brt-03 | 60 | 8 | 28.5 | 195 |
|
||||
| FD-zap-10 | 60 | 10 | 20.5 | 120 |
|
||||
| FD-agm-02 | 60 | 10 | 25.5 | 150 |
|
||||
| FD-nob-04 | 60 | 10 | 25.5 | 204 |
|
||||
| FD-bre-20 | 60 | 10 | 25.5 | 210 |
|
||||
| FD-taa-01 | 65 | 6 | 29 | 210 |
|
||||
| FD-uge-53 | 65 | 6 | 29 | 220 |
|
||||
| FD-hym-03 | 80 | 13 | 24.5 | 265 |
|
||||
| FD-hym-04 | 80 | 13 | 24.5 | 345 |
|
||||
| FD-pro-04 | 80 | 13 | 30 | 300 |
|
||||
| FD-pro-03 | 80 | 13 | 30 | 330 |
|
||||
Straight Flails Slotted Hole
| Part Number | Width | Thickness | Hole Size | Length |
|---|---|---|---|---|
| FD-ama-61 | 30 | 2 | 10 x 14 | 87 |
|
||||
| FD-uni-24 | 30 | 3 | 8 x 10.5 | 85 |
|
||||
| FD-410527 | 30 | 3 | 8.5 x 13 | 85 |
|
||||
| FD-ama-56 | 30 | 3 | 10 x 16.5 | 87 |
|
||||
| FD-uni-19 | 30 | 3 | 10 x 17 | 90 |
|
||||
| FD-rye-03 | 30 | 3 | 13 x 25 | 135 |
|
||||
| FD-prz-900 | 30 | 3 | 13 x 27 | 135 |
|
||||
| FD-sm-04 | 40 | 5 | 14 x 30 | 81 |
|
||||
| FD-fei-58 | 40 | 6 | 14 x 30 | 80 |
|
||||
| FD-fei-49 | 40 | 6 | 16.5 x 34 | 104 |
|
||||
| FD-hym-11 | 40 | 6 | 16.5 x 34.5 | 113 |
|
||||
